Goldring Elite (MC)

Moving Coil Cartridge

Frequency Response : 20 Hz-30 kHz +/- 2 dB
Channel Balance : within 1 dB @ 1 kHz
Channel Separation : better than 25 dB @ 1 kHz
Sensitivity : 0.5 mV +/- 1 dB @ 1 kHz
Static Compliance : 18 mm/N
Equivalent tip mass : 0.35 mg
Vertical Tracking Angle : 20 °
Stylus Radius : Gyger S
Stylus Type : Non-Replaceable
Load Resistance : 100 Ω
Load Capacitance : 100 – 500 pF
Internal Inductance : 2 uH
Internal Resistance : 8 Ω
Cartridge Mass : 5.7 g
Cartridge Mass (inc. fixings) : 6.6 g
Fixing Centre : 0.5 ” (12.7 mm)
Playing Weight : 1.5 – 2.0 g (1.7 g nom.)
